Ariens Arrow 36

Ariens Arrow 36 Zero-Turn Mower Powered by Kawasaki

RRP: £11,355

Featuring all the benefits of a zero-turn mower but with the low-profile form of a large walk-behind mower and near perfect visibility of the cutting area. The ARROW stand-on can quickly mow larger lawns yet also cut intricate shaped grass dotted with trees, flower beds and other obstacles. Accelerate your commercial cutting workflow with the 'hop on, hop off' driving style of this stand-on zero-turn.

With its standard Kawasaki FS600 engine and 91 cm (36″) long mower deck, the ARROW 36 stand-on mower is the commercial choice for mowing in all areas.

Features:

• Equipped with a 91 cm (36″) wide cutting deck made of 4.5 mm sheet steel

• Powered by a Kawasaki® FS 600 V-Twin 600cc engine

• Height adjustment via foot pedal and pin system in 15 steps

• A range of accessories is available

• 5 years or 1000 hours warranty – no hour limit for the first 2 years

Easy access and high manoeuvrability

Both the 81 cm (32″) and 91 cm (36″) mowing decks provide access to hard-to-reach mowing areas and make it easier to work in confined spaces. Mounting and dismounting takes just seconds.

Folding platform

The upright position of the driver on the platform offers the user a better view of the cutting deck than with a ride-on mower. Vibrations and impacts on the operator's back are reduced - a working day is less stressful. The platform's folding mechanism allows a quick transformation from a ‘stand-on’ to a ‘walk-behind’ mower, giving the user maximum versatility in narrow and low passages.

Adjustable speed control

Enables the driver to limit the maximum speed of the machine in confined working environments.

Operating elements

All functions are within easy reach and ergonomically controllable from the driver's position.

Cutting height adjustment

Less effort required to raise the mower deck, a combination of foot pedal and hand lever and a vertical pin system make it easier to adjust the cutting height.

Premium engine

A Kawasaki FS600 V-Twin premium engine provides power, performance and fuel efficiency.

Lower center of gravity

The geometry and weight distribution ensure greater stability on inclines and a more pleasant feeling of safety for the rider.

Specification:

• Motor: Kawasaki® FS600 V-Twin

• Engine Displacement: 603cc

• Starter: Electric

• Deck Material: 4.5 mm sheet steel

• Deck Construction: Welded

• Number of Spindles: 2

• Spindle Housing: Forged Aluminium

• Spindle Shaft: Steel, StressProof®

• Spindles drive: V-belt

• Spindle Clutch: Electric Ogura®

• Cutting Width: 91cm (36")

• Cutting Height Min: 3.8cm - 12.7cm (1.5" - 5.0")

• Warranty Machine: 5 Year / 1000 Hours

• Drive Type: Hydro-Gear® ZT-3100 Transaxles

• Fuel Capacity: 22.7 ltr

• Ground Speed Forward: 12.8kph / 8mph

• Ground Speed Reverse: 4.8 kph / 3mph

• Deck Lift System: Manual

• Cutting Positions: 15

• Wheels Front: 11 x 4.00 - 5 semi-pneumatic

• Wheels Rear: 18 x 8.50 - 8 radial

• Weight: 357 kg (787lbs)

• Length: 160 cm, driver platform folded; 190 cm, driver platform unfolded

• Width: 124 cm w/ chute; 94 cm w/ mulch kit

• Height: 122 cm
